DigiBrass Specifications
Technical details for the Tilt and Tipsy
MIDI Outputs
- ▶USB MIDI (class compliant)
- ▶BLE MIDI (wireless)
- ▶MIDI cable (through TRS-A jack)
Internal Synthesizers
| General MIDI synthesizer | Complies with the General MIDI synthesizer specification at MIDI.org. Includes 128 standard sounds including keyboards, strings, winds, and percussion. |
| Four-voice additive synth | This customizable synth can mix 4 separate voices with differing waveforms and with custom filtering and reverberation. |
| Mixed | Use a blend of these two synths. |
Audio Outputs (for Internal Synths)
- ▶1/8" (3.5mm) Headphone Jack (amplified)
- ▶1/8" (3.5mm) Line Out
- ▶USB C Audio Out (USB class compliant)
Power and Battery
- ▶Internal Lithium Polymer Battery
- ▶Charging through USB C jack
- ▶Play while charging
MIDI Implementation Chart
According to the MIDI Manufacturers Association (MIDI.org), MIDI devices should have a MIDI Implementation Chart that defines how the instrument complies with the MIDI standard.
| MIDI Message | Supported | Details |
|---|---|---|
| Note On and Note Off | Yes | Note off can be configured as note off messages or note on with velocity zero. |
| Expression | Yes | CC 2 and/or CC 11 are supported for breath expression |
| Pitch Bend | Yes | |
| Pitch Bend Range | Yes | Configurable between zero and 24 semitones at the preset level |
| Program Change | Yes | Configured per preset |
| Continuous Controllers | Yes | Any CC can be used for toggling or sliding CC values |
| All Notes Off | Yes |
